The delta tune is the CB name for a very similar function on amateur radios called RIT, or receive incremental tuner. The Delta Tune controls the frequency your radio's receiver is operating on.

What does Dynamike do on a CB?

DYNAMIKE - This control amplifies your voice to make you sound louder. It is like a built-in power mike. Normally you would have this control turned all the way up. If you are using a power mike and you experience squealing or distortion, try turning down the Dynamike.

How do you make a CB go farther?

The best way to extend the range of your CB, or any radio, is raise the antenna higher. Of course you will need a good quality antenna and Coax. For mobile operations the Wilson 5000 is probably the best.

What is a clarifier on a CB radio?

A "clarifier" is a small control that lets you compensate and fix this variation in frequency. With a little effort, you can receive the SSB signal on your CB radio exactly as it was in the original audio.

What is RIT in amateur radio?

Receiver incremental tuning (RIT)--A transceiver control that allows for a slight change in the receiver frequency without changing the transmitter frequency.

CB Radio for Beginners Part 9 Using the Cobra 29 LX Delta Tune Knob

Why is CB limited to 4 watts?

The FCC allows a maximum of 4 watts of output power for CB radios to avoid signal interference with other devices, such as TV and emergency communication radios.

Are dual CB antennas better?

With antennas on both sides of your vehicle, you're much less likely to have large dead spots because the antenna system can "see" more. This is one of the primary reasons most 18 wheelers have dual antenna setups.

How far will my CB reach?

Terrain plays a large role, as there is much more variation in a 25- to 50-mile transmission radius than a smaller 5-mile radius for a mobile antenna. However, a properly installed base antenna can usually provided at least 15 miles of range and often significantly more.

What does the RF gain do on a CB?

To counteract noise, RF gain acts as a sensitivity filter. It reduces noise in the receiver without reducing reception power as a CB radio squelch does.

Why is my SWR so high?

One of the most common causes of high SWR readings is incorrectly connecting your SWR meter to your radio and antenna. When attached incorrectly, readings will be reported as being extremely high even if everything is installed perfectly.

What is the most powerful CB radio?

Welcome to the most powerful CB radio available, the Ranger RCI 69FFB4. Boasting over 400 watts PeP, this Ranger CB radio puts everything else to shame in terms of sheer performance.

What is Channel 19 on a CB radio?

Any authorized CB radio frequency is open to all, but some have agreed-upon special purposes. For instance, channel 9 is for emergency use, and channel 19 is used by truckers to report on traffic conditions. Channel 19 is at the middle of the bands, thus has the best antenna efficiency.

How do you tell if your CB antenna is grounded properly?

If your CB antenna mount has a good ground, the multimeter needle should move all the way to the right when the probes contact these two locations. If you get very little or no needle movement on the multimeter, test that your meter is working properly by touching the two probes together.

How far will a 4 watt CB transmit?

Transmitter power is limited to 4 watts in the US and the EU. CB radios have a range of about 3 miles (4.8 km) to 20 miles (32 km) depending on terrain, for line of sight communication; however, various radio propagation conditions may intermittently allow communication over much greater distances.

What is the longest range CB radio?

Best Long Range CB - The Cobra 148 GTL

While most CB radios broadcast at 4 watts of power, SSB equipped radios can legally broadcast at 12 watts - effectively tripling the distance you can broadcast.

Is CB Channel 9 still monitored?

"We do not routinely monitor Channel 9," he added.

What does 73 mean in ham lingo?

73 is an old telegraph code that means "best regards". 73, as well as 88 (which means "hugs and kisses") are part of the language of ham radio.

What is 72 in ham radio?

This use of 72 goes back at least to the early 1990s. While “best regards” may be the formal definition of 73 these days, we use it in a much less formal, much more cordial way these days. We're not just saying “good bye,” but also “thanks” and “hope to see you again soon.” And, with that, 73 from Dan, KB6NU.

What does QSO mean in ham radio?

Ham Radio operators still make liberal use of them today. A QSO is another word for “contact,” as in “I made 783 QSOs during Field Day last year!” or “Making QSOs with European stations was difficult during the contest.” Many Hams enjoy keeping a record of stations they've made QSOs with by writing them in a log book.

How do I bring a SWR down?

If your antenna is mounted down low on the vehicle, like on the bumper or behind a pickup truck's cab, the signal can bounce back to the antenna, causing a high SWR. To alleviate this, keep at least the top 12 inches of the antenna above the roof line, and position the antenna as high as possible on the vehicle.

What SWR can damage a radio?

SWR 3.0+: Performance will be severely affected, and you're likely to damage your radio with extended transmission use. You SHOULD NOT transmit with your CB at SWR levels above 3.0.

Why does my CB squeal?

Excessively high SWR may cause squealing (and also results in short range). Try running a ground wire to a screw on the side of the radio. If you are using a power microphone, try turning the gain down. Also try using the original microphone.
